Drying Conveyor
- Mã sản phẩm: BT03
- Lượt xem: 3165
Currently, the need to dry products and goods is extremely important in the food industry, processing agricultural products, seafood, textiles, sandwiches, helping to store and preserve better. To solve this problem, the application of drying conveyor systems in production helps to improve work efficiency.
Conveyor dryer (conveyor dryer) is a device used to dry materials in food, chemicals... New improved conveyor dryer, with outstanding advanced technology, meets the requirements drying at high temperature while ensuring the durability of the conveyor belt. Drying conveyor is designed with high heat resistance, good and stable operation in harsh environments, ensures safety during the drying process thanks to the system of alarms, roles,... Especially, when the conveyor is running, The new drying oven works to ensure that the conveyor belt is not damaged. When problems occur, the dryer will automatically turn off and have an error alarm for timely detection.
![Heat drying conveyor]( "Heat drying conveyor")
The materials to be dried will be spread evenly on the surface of the conveyor through a specialized feeding device. The drying conveyor starts to work, hot wind will be blown into the material from the top to the bottom of the conveyor in the drying chamber. Produces uniform heating of the entire drying material. So that the entire material on the conveyor will be exposed to high temperature, hot wind helps to increase heat very quickly.
The drying process depends on the input materials. The drying chamber is sealed, so no heat is lost to the outside, making the drying process faster, increasing the efficiency of use. Conveyor dryer equipment is suitable for raw materials with definite shapes: Vegetables, fruits, herbs, aquatic products, animal food or some other chemical products.
The drying conveyor is a mechanical device designed and manufactured specifically for each type of drying product. Therefore, customers need to consider when choosing the right drying equipment so as not to affect the product. Take a look at some of our drying conveyors for the best selection.
Floor drying conveyor is designed with the ability to dry products quickly, for each type of drying material, you can adjust the temperature of the drying chamber accordingly to be able to dry the product effectively. The conveyor is designed to help exchange heat, save energy and provide high drying efficiency. The drying chamber is equipped with drying balls and a fan to help circulate the temperature evenly in the drying chamber, so that the products dry faster.
* Structure of 1st floor drying conveyor:
In addition to 1-stage drying conveyor, customers can also choose 2-, 3-, and multi-layer drying conveyors to increase the ability to transport and dry products. The multi-stage conveyor helps to evenly dry all sides of the product, shortening the drying time and improving the drying quality. Depending on the intended use of the customer, it is possible to choose the appropriate drying floor design to ensure a reasonable cost.
![Băng tải sấy nhiệt]( "Băng tải sấy nhiệt")
This type of conveyor is specialized for use in the food processing industry. The purpose of the drying conveyor is to reduce the volume of raw materials, to dry them for better preservation and to improve the value of the product.
* Structure of food drying conveyor:
* Advantages of food drying conveyor:
Depending on the different types of drying materials, you choose the size of the drying chamber and the appropriate drying temperature to ensure the right product quality. With outstanding advantages, food drying conveyor belt is the first choice for food production and processing facilities.
![Food drying conveyor]( "Food drying conveyor")
Drying conveyor capable of working in severe conditions ensures high performance, bringing economic value to users. To order drying conveyors, please contact Intech Group. We specialize in assembling and manufacturing drying conveyors with many different designs and sizes. Some drying systems that we manufacture such as: agricultural dryers, food dryers, thermal drying conveyors, etc. Depending on the needs of each business, choose suitable conveyor lines to increase efficiency. results at work.
Please send us your requirements for the type of conveyor you need. Information about drying products including type, size, weight so that we can design the most suitable type of conveyor. Conveyor structure, material selection, number of drying floors... will determine the price of the drying conveyor. We will send the drying conveyor quote with your requirements. Please contact us today for the best support, Hotline: 024 66 806 795
What is a drying conveyor?
Conveyor dryer (conveyor dryer) is a device used to dry materials in food, chemicals... New improved conveyor dryer, with outstanding advanced technology, meets the requirements drying at high temperature while ensuring the durability of the conveyor belt. Drying conveyor is designed with high heat resistance, good and stable operation in harsh environments, ensures safety during the drying process thanks to the system of alarms, roles,... Especially, when the conveyor is running, The new drying oven works to ensure that the conveyor belt is not damaged. When problems occur, the dryer will automatically turn off and have an error alarm for timely detection.
Structure of thermal drying conveyor:
- Conveyor frame is made of stainless steel, powder coated steel or profiled aluminum.
- Heat resistant PVC and PU tape.
- The drying cabinet is insulated with glass wool.
- The heater helps to maintain and stabilize the temperature in the drying chamber.
- Geared motor and controller.
Working principle of conveyor drying equipment
The materials to be dried will be spread evenly on the surface of the conveyor through a specialized feeding device. The drying conveyor starts to work, hot wind will be blown into the material from the top to the bottom of the conveyor in the drying chamber. Produces uniform heating of the entire drying material. So that the entire material on the conveyor will be exposed to high temperature, hot wind helps to increase heat very quickly.
The drying process depends on the input materials. The drying chamber is sealed, so no heat is lost to the outside, making the drying process faster, increasing the efficiency of use. Conveyor dryer equipment is suitable for raw materials with definite shapes: Vegetables, fruits, herbs, aquatic products, animal food or some other chemical products.
Types of drying conveyors commonly used today:
The drying conveyor is a mechanical device designed and manufactured specifically for each type of drying product. Therefore, customers need to consider when choosing the right drying equipment so as not to affect the product. Take a look at some of our drying conveyors for the best selection.
1 - Floor drying conveyor
Floor drying conveyor is designed with the ability to dry products quickly, for each type of drying material, you can adjust the temperature of the drying chamber accordingly to be able to dry the product effectively. The conveyor is designed to help exchange heat, save energy and provide high drying efficiency. The drying chamber is equipped with drying balls and a fan to help circulate the temperature evenly in the drying chamber, so that the products dry faster.
* Structure of 1st floor drying conveyor:
- Dimensions: W400*L3000*H750mm
- 30x60 aluminum profile frame.
- PU tape is resistant to temperatures of 80 degrees Celsius.
- Stainless steel tape support plate 201.
- 180W geared motor.
- Drying system W400*L6000*H300mm
- Includes 2 pairs of drying balls, 1400mm long.
- 2-layer stainless steel shell, with insulation layer.
- There are 4 heat island fans to make the temperature stable.
In addition to 1-stage drying conveyor, customers can also choose 2-, 3-, and multi-layer drying conveyors to increase the ability to transport and dry products. The multi-stage conveyor helps to evenly dry all sides of the product, shortening the drying time and improving the drying quality. Depending on the intended use of the customer, it is possible to choose the appropriate drying floor design to ensure a reasonable cost.
2 - Food drying conveyor
This type of conveyor is specialized for use in the food processing industry. The purpose of the drying conveyor is to reduce the volume of raw materials, to dry them for better preservation and to improve the value of the product.
* Structure of food drying conveyor:
- Dimensions: W630xL6000
- Frame in NDH 40x80
- Geared motor 180W
- Control cabinet
- Insulated drying chamber
- 6 fans/drying chamber
- Drying ball 1.2m, 3 balls/ Drying chamber
- PVC Belt t=3mm
- The temperature is 80 degrees C
* Advantages of food drying conveyor:
- Conveyor belt helps to evenly dry all sides of the product
- The drying material is spread evenly on the conveyor belt to make the drying process faster and more even
- Can be heated midway, control air flow easily
- High drying efficiency, saving electricity in the production process
- Easy to use, install, operate and maintain
Depending on the different types of drying materials, you choose the size of the drying chamber and the appropriate drying temperature to ensure the right product quality. With outstanding advantages, food drying conveyor belt is the first choice for food production and processing facilities.
Advantages of conveyor dryer equipment
- The thermal drying conveyor system is compactly designed, takes up less space in the factory and improves product drying efficiency.
- In particular, with the closed drying process, it saves fuel and minimizes drying fuel consumption.
- The drying temperature can be adjusted to suit different types of drying products.
- Conveyor dryer is very heat resistant, temperature from 80 - 260 degrees Celsius.
Quotation of the latest thermal drying conveyor
Drying conveyor capable of working in severe conditions ensures high performance, bringing economic value to users. To order drying conveyors, please contact Intech Group. We specialize in assembling and manufacturing drying conveyors with many different designs and sizes. Some drying systems that we manufacture such as: agricultural dryers, food dryers, thermal drying conveyors, etc. Depending on the needs of each business, choose suitable conveyor lines to increase efficiency. results at work.
Please send us your requirements for the type of conveyor you need. Information about drying products including type, size, weight so that we can design the most suitable type of conveyor. Conveyor structure, material selection, number of drying floors... will determine the price of the drying conveyor. We will send the drying conveyor quote with your requirements. Please contact us today for the best support, Hotline: 024 66 806 795
